Eibach 40494 ERS Main-Metric - Dia. 1.42 in | Len: 4.37 in | Rate: 600 lbs/in

Features

Eibach's METRIC Coilover Springs are designed to precise tolerances featuringEibach'slegendary consistency in rate, linearity and measurement. The original spring trusted by racers around the world.

• 36mm I.D. Formula Springs Available in a Full Range of Rates
• Maximum Travel in Combination with Smallest Block Heights
• Lowest Side Loads with Load Center Ideally Located Relative to the Spring Axis
• Precision Tolerances - The Tightest in the Industry
• Each Spring Individually Tested and Rated

Specifications

Formula Spring

Length (in)	Diameter (in)	Rate (lbs/in)	Block Height (in)	Travel (in)	Block Load (lbs)	Weight (lbs)
4.37	1.42 I.D.	600	2.32	2.05	1236.00	0.93
Length (mm)	Diameter (mm)	Rate (kg/mm)	Block Height (mm)	Travel (mm)	Block Load (N)	Weight (kg)
111.00	36.00 I.D.	10.71	59.00	52.00	5500.00	0.42
