Eibach
Eibach 60-60-0070 INDIVIDUAL COILOVER RACE SPRING MIDDLE 60MM INSIDE DIAMETER RED
Eibach 60-60-0070 INDIVIDUAL COILOVER RACE SPRING MIDDLE 60MM INSIDE DIAMETER RED
Regular price
$80.00
Regular price
$88.89
Sale price
$80.00
Unit price
/
per
Couldn't load pickup availability
Eibach 60-60-0070 ERS Main-Metric - Dia. 2.36 in | Len: 4.69 in | Rate: 400 lbs/in
Features
Eibach's METRIC Coilover Springs are designed to precise tolerances featuringEibach'slegendary consistency in rate, linearity and measurement. The original spring trusted by racers around the world.- Provides a Softer Initial Rate When Paired with a Main Spring
- Available in Linear or Progressive Rates
- Each Spring Individually Tested
- Highest Linearity and Guaranteed Consistency
Specifications
Tender Spring (Linear)| Length (in) | Diameter (in) | Rate (lbs/in) | Block Height (in) | Travel (in) | Block Load (lbs) | Weight (lbs) |
|---|---|---|---|---|---|---|
| 4.69 | 2.36 I.D. | 400 | 2.32 | 2.36 | 944.00 | 2.56 |
| Length (mm) | Diameter (mm) | Rate (kg/mm) | Block Height (mm) | Travel (mm) | Block Load (N) | Weight (kg) |
| 119.00 | 60.00 I.D. | 7.14 | 59.00 | 60.00 | 4200.00 | 1.16 |
